ABOUT YOUR THERMOSTATS
HTW-CCF-702AWF Modern Touch Screen Room Thermostats are designed to on/off control the fans and valves in air conditioner applications via comparison of the room temperature and setting temp. as reaching the aim of comfort and saving energyTECHNICAL DATA
Power Supply:95 ~240 VAC, 50~60HzFan Relay Amps Resistance: 5A; Inductive: 3AValve Relay Amps Resistance: 3A; Inductive: 1ASensor: NTC3950, 10KSet Temp. Range: 5 -35 ℃Accuracy: ±0.5 ℃Dispaly Temp. Range: 5 ~ 99℃Ambient Temp.:0~45 ℃Ambient Humidity: 5 ~ 95 % RH (Non Condensing)Storage Temp.:-5~ 55 ℃Timing Error: < 1%Power Consumption: <1.5WShell Material: PC +ABS ( Fireproof)Wire Terminals: Wire 2 X 1.5 mm² or 1 x2.5 mm²Protection Class: IP20Buttons: Capactive Touch ButtonsFEATURES
On Appearance1.White or Blue backlight will show you a nice world.2. Ф 50mm display area helps to protect your eyes.3. High-transparency acrylic lenses to highlight fashion.4. Touch buttons to make simple operation.5. Convenient wall mounting.6. The visible thickness above the wall is only 20.5 mm.7. White simple design, elegant and fashionableOn Functionality1. Powerful functions are available such as Modbus/WIFI etc.2. ±1°C Accuracy keeps temperature within the level you set.3. Data memory when power is off.4. 5+1+1 six periods programmable maximize comfort and economy.5. Create thermostat group to Centralized control6. Integrate with Amazon Echo, Google Home.7. All setting languages synchronize your time zone, address and language.8. No limit to add rooms and support Smart Scene.
